1-4000 Nm Dial torque wrench,ACD Series
-
Accuracy ±3% Brand SAIVS Customized OEM,ODM Driver(inch) 3/8，1/2，3/4，1，3/2, 1 /4 L/W/H(mm) 275-2000/76-110/58-145 Minimum Order 1Piece Model Number ACD Place of Origin China Torque range(Nm) 1-4000Nm Weight(kg) 0.64-18.4 - 150-500Nm,Pneumatic Torque Wrench,SFW5A 1800-6000Nm,Pneumatic Torque Wrench,SFW60A 240-800Nm,Pneumatic Torque Wrench,SFW8A 2400-8000Nm,Pneumatic Torque Wrench,SFW80A 3000-10000Nm,Pneumatic Torque Wrench,SFW100A 3600-12000Nm,Pneumatic Torque Wrench,SFW120A 405-1350 Nm,Pneumatic Torque Wrench,SFW14A 600-2000Nm,Pneumatic Torque Wrench,SFW20A 80-300Nm,Pneumatic Torque Wrench,SFW3A Pneumatic Torque Wrench SFW-A Series
Description
Accuracy: Level 3, offering highly accurate
measurements with a maximum error range of ± 3%.
Shell: The robust exterior is meticulously crafted
using premium-grade aluminum alloy,
ensuring durability and longevity.
High torque accuracy and stability:
This exceptional device guarantees precise torque measurements
while maintaining excellent stability throughout operation.
Image Gallery
Dimensions
| ACD Type Dial torque wrench | |||||||
| Model Number | Torque range | Driver/inch | Length/mm | Width/mm | Height/mm | Weight/kg | Fine Scale/N.m |
| ACD 19901 | 1-5 | 1/4" | 275 | 76 | 58 | 0.64 | 0.05 |
| ACD 19902 | 2-10 | 3/8" | 275 | 76 | 67 | 0.65 | 0.1 |
| ACD 19903 | 6-30 | 3/8" | 275 | 76 | 67 | 0.65 | 0.25 |
| ACD 19904 | 10-50 | 1/2" | 305 | 76 | 70 | 0.77 | 0.5 |
| ACD 19905 | 20-100 | 1/2" | 305 | 76 | 70 | 0.77 | 1 |
| ACD 19906 | 40-200 | 1/2" | 600 | 76 | 76 | 1.66 | 2 |
| ACD 19907 | 60-300 | 1/2" | 600 | 76 | 76 | 1.7 | 3 |
| ACD 19908 | 100-500 | 3/4" | 900 | 76 | 97 | 3.9 | 5 |
| ACD 19909 | 150-750 | 3/4" | 900 | 76 | 97 | 3.9 | 5 |
| ACD 19910* | 200-1000 | 3/4" | 900+550（1450） | 76 | 103 | 5.3+2.1 | 10 |
| ACD 19911* | 400-2000 | 1" | 900+550（1450） | 76 | 103 | 5.3+2.1 | 20 |
| ACD 19912* | 1000-3000 | 1、3/2" | 1450+550（2000） | 110 | 145 | 16.3+2.1 | 50 |
| ACD 19913* | 2000-4000 | 1、3/2" | 1450+550（2000） | 110 | 145 | 16.3+2.1 | 50 |
Details
Application
Repairing small engines
Maintaining firearms
Working on lawnmower blades
Attaching roof trusses
Installing pipeline components
Erecting wind turbines
Heavy equipment maintenance
Video
Literature
- 1.Working principle of manual torque wrenches
- 2.Repair Methods For Digital Torque Wrench
- 3.How Often Should I Calibrate My Torque Wrench
- 4.Types of Manual Torque Wrenches
- 5.Precautions for using preset torque wrenches
- 6.Basic knowledge of dial torque wrench
FAQs
Are dial torque wrenches more accurate?
Dial torque wrenches are known for their high accuracy.
They typically offer better accuracy compared to click-type torque wrenches.
Most dial torque wrenches have a precision within a range of +/- 2-3% of the indicated value.
This level of accuracy makes them suitable for applications where precise torque measurement
is crucial, such as in critical assemblies or industries
that require strict adherence to torque specifications.
How do you use a dial torque wrench?
1. Set the desired torque value on the wrench by rotating the handle or adjusting the calibration knob.
2. Attach the appropriate socket or bit to the wrench.
3. Position the wrench onto the fastener and apply force in a controlled and steady manner.
4. Monitor the dial indicator while applying force, ensuring it stays within the desired torque range.
5. Once the needle reaches the target torque value, stop applying force.
6. Verify that the fastener is securely tightened and check the dial
indicator to ensure the applied torque matches the desired value.
7. Store the wrench properly to maintain its accuracy and longevity.
Note: Always follow the manufacturer's instructions for specific usage guidelines and maintenance procedures.
