1-500 Nm Plug-In Torque Wrench,TG-1 Series
-
Accuracy ±4% Brand SAIVS Customized OEM,ODM L/W/H(mm) 230-645/28-36/ 28-36 Minimum Order 1Piece Model Number TG-1 Place of Origin China Specification 9x12, 14x18 Torque range(Nm) 1-500Nm Weight(kg) 0.5-2 - 150-500Nm,Pneumatic Torque Wrench,SFW5A 1800-6000Nm,Pneumatic Torque Wrench,SFW60A 240-800Nm,Pneumatic Torque Wrench,SFW8A 2400-8000Nm,Pneumatic Torque Wrench,SFW80A 3000-10000Nm,Pneumatic Torque Wrench,SFW100A 3600-12000Nm,Pneumatic Torque Wrench,SFW120A 405-1350 Nm,Pneumatic Torque Wrench,SFW14A 600-2000Nm,Pneumatic Torque Wrench,SFW20A 80-300Nm,Pneumatic Torque Wrench,SFW3A Pneumatic Torque Wrench SFW-A Series
Description
Accuracy: Level 4, delivering exceptional
precision and accuracy in measurements
Error range: Within ± 4%, guaranteeing precise
and consistent results for reliable measurements every time.
Component: Meticulously crafted using high-
quality alloy steel for durability and Performance
Equipped with an elastic pin design,
facilitating easy replacement when needed
Image Gallery
Dimensions
| TG-1 type Plug-in torque wrench | |||||||
| Model Number | Torque range | Specification | Length/mm | Width/mm | Height/mm | Weight/kg | Fine Scal/N.m |
| TG02301 | 1-5 | 9x12 | 230 | 28 | 28 | 0.5 | 0.2 |
| TG02302 | 2-10 | 9x12 | 230 | 28 | 28 | 0.5 | 0.5 |
| TG02303 | 5-25 | 9x12 | 230 | 28 | 28 | 0.5 | 0.5 |
| TG02304 | 8-40 | 9x12 | 230 | 28 | 28 | 0.5 | 1 |
| TG02305 | 10-50 | 9x12 | 230 | 31 | 31 | 1 | 1 |
| TG02306 | 20-100 | 9x12 | 405 | 31 | 31 | 1 | 7.5 |
| TG02307 | 40-200 | 9x12 | 405 | 31 | 31 | 2 | 7.5 |
| TG02308 | 60-300 | 14x18 | 595 | 36 | 36 | 2 | 10 |
| TG02309 | 150-450 | 14x18 | 645 | 36 | 36 | 2 | 10 |
| TG02310 | 100-500 | 14x18 | 645 | 36 | 36 | 2 | 10 |
Details
Application
Mounting electrical panels
Installing door hardware
Erecting wind turbines
Heavy equipment maintenance
Bridge construction
Precision instrument assembly
Electronics assembly
Video
Literature
- 1.Working principle of manual torque wrenches
- 2.Repair Methods For Digital Torque Wrench
- 3.How Often Should I Calibrate My Torque Wrench
- 4.Types of Manual Torque Wrenches
- 5.Precautions for using preset torque wrenches
- 6.Basic knowledge of dial torque wrench
FAQs
What are the advantages of using a plug-in torque wrench?
1. Increased efficiency: By utilizing power tools, plug-in torque
wrenches allow for faster torque application, reducing assembly time.
2. Consistent torque: The power tools provide a more controlled
and uniform torque output, ensuring consistent fastening results.
3. Versatility: Plug-in torque wrenches can handle a wide range of
torque requirements, accommodating various fastener sizes and torque specifications.
4. Reduced operator fatigue: Using power tools reduces the physical
exertion required by the operator, minimizing fatigue during extended use.
Are plug-in torque wrenches suitable for all applications?
1. Torque accuracy: If precise torque control is necessary, such as in precision
instrumentation or delicate assembly work, hand-operated torque wrenches may be more appropriate.
2. Access limitations: In cases where a power tool cannot reach the fastener
due to restricted access or space limitations, a plug-in torque wrench may not be viable.
3. Cost considerations: Plug-in torque wrenches often require an investment in power
tools and accessories, which may not be justifiable for occasional or low-volume torque applications.
It's important to evaluate the specific requirements of each application
to determine if a plug-in torque wrench is the most suitable option.
