RRH Series Double-Acting Hollow Cylinders Jack
-
Brand Name Replacement Enerpac's RRH Series Country of Origin China Manufacturer SAIVS Max.pressure 700 Bar/10000 Psi Model RRH Series Plunger Type Solid Return Type Single-Acting Spring Return Stroke 38-258 mm Weight 21-111 KG Other Parameters Hydraulic Cylinder Capacity: 30-150 ton Mounting Hole Thread Depth: 14-19 mm - RRH Series Double-Acting Hollow Cylinders Jack RRH1003, 100 ton 947 KN, 76 mm 2.99 in Stroke, Double Acting Hollow Cylinders RRH10010, 100 ton 947 KN, 257 mm 10.12 in Stroke, Double Acting Hollow Cylinders RRH1001, 100 ton 947 KN, 38 mm 1.50 in Stroke, Double Acting Hollow Cylinders RRH1006, 100 ton 947 KN, 153 mm 6.02 in Stroke, Double Acting Hollow Cylinders RRH1508, 150 ton 1445 KN, 203 mm 7.99 in Stroke, Double Acting Hollow Cylinders RRH3010, 30 ton 336 KN, 258 mm 10.16 in Stroke, Double Acting Hollow Cylinders RRH307, 30 ton 336 KN, 178 mm 7.01 in Stroke, Double Acting Hollow Cylinders RRH6010, 60 ton 589 KN, 257 mm 10.12 in Stroke, Double Acting Hollow Cylinders RRH603, 60 ton 589 KN, 89 mm 3.50 in Stroke, Double Acting Hollow Cylinders
Description
- Model:RRH Series
- Product Line: Industrial Tools
- Type: Hydraulic Cylinder Ram, Hydraulic Jacks
Double-Acting cylinder version for fast retraction.
Hollow Plunger design allows for both,pull and push forces.
Dual dust-proof ring structure remains cylinder internal cleaning.
The exclusive guide ring is designed absorbs eccentric loading without galling cylinder parts,reduces wear and extending life.
Built-in safety valve prevents accidental over pressurization.
Special painted surface to increase corrosion resistance.
Easy fixturing with collar threads,plunger threads and base mounting holes.
All model include quick couplings (NPT3/8"-18) and dust-proof cap.
Floating center tube is designed to increase product life.
Customizable with special requirement.
Pump Selection
Selection appropriate pumps for offer optimum combination .For details, please refer to the section "hydraulic pumps".
hoses
Select SAIVS high quality high pressure hoses. For details, please refer to the section "Hydraulic Components".
- Material:CR40
- Manufacturer:SAIVS
- Country of Origin:China
- Minimum Order:1 Piece
- Customizable with special requirement
