FA9TESTD, 10 Ton 31.5 mm, Hydraulic Flange Alignment Tool
-
Alignment Capacity 10 ton | 89.0 kN Brand Name Replacement Enerpac's FA9TESTD Country of Origin China Manufacturer SAIVS Min. Bolt Size 31.5mm | 1.24inch Minimum Order 1 Piece Model FA9TESTD Series FA Type Integral Hydraulic Weight 16.5 kg | 36.4 lbs - SWi12/14TM 15.7 Ton Mechanical Flange Spreader STF14H 14 Ton 3.16 in Hydraulic Flange Spreader Set SW14.5TI, 14.5 Ton Integral Hydraulic Flange Spreader SWi2025TE 26.9 Ton 250 cm³ Hydraulic Flange Spreader SWI20/25TI 26.9 Ton Integral Hydraulic Flange Spreader SWi5TI-S 8.7 Ton 4 in Integral Hydraulic Flange Spreader Set SWi5TE-S 8.7 Ton External Hydraulic Flange Spreader SWi2025TEMAXSPB 26.9 Ton 250 cm³ External Hydraulic Flange Spreader Maxi Set FA1TMSTD, 1 Ton 16 mm, Mechanical Flange Alignment Tool FA4TMSTD, 4 Ton 24 mm, Mechanical Flange Alignment Tool
Description
Model:FA9TESTD
Product Line: Industrial Tools
Customizable with special requirement
The FA9TE Hydraulic Linear & Rotational Flange Alignment Tool is a simple solution to large-diameter high-pressure flange joint misalignment.
The FA9TESTD Set includes:
1 x FA9TE Tool including Hydraulic Cylinder
1 x Instruction Manual
1 x Carry-Case
1 x Ratchet & Strap
Image Gallery
Dimensions
| Alignment Capacity(Ton) | 10 |
| Min. Bolt Size(mm) | 31.5 |
| Min. Bolt Size(inch) | 1.24 |
| Flange Thickness(mm) | 93-228 |
| Flange Thickness(inch) | 3.66-9 |
| Type | Split Type Hydraulic |
| Weight (kg) | 16.5 |
Details
Series Comparison
| Model | Alignment Capacity(Ton) | Min. Bolt Size(mm) | Min. Bolt Size(inch) | Flange Thickness(mm) | Flange Thickness(inch) | Type | Weight (kg) |
| FA1TMSTD | 1 Ton | 8.9 kN | 16 | 0.63 | 14-82 | 0.55-3.29 | Mechanical | 2 | 4.4 lbs |
| FA4TMSTD | 4 Ton | 35.6 kN | 24 | 0.95 | 30-133 | 1.18-5.23 | Mechanical | 8.6 | 19.0 lbs |
| FA9TMSTD | 10 ton | 89.0 kN | 31.5 | 1.24 | 93-228 | 3.66-9 | Integral Hydraulic | 16.5 | 36.4 lbs |
| FA9TESTD | 10 ton | 89.0 kN | 31.5 | 1.24 | 93-228 | 3.66-9 | Split Hydraulic | 16.5 | 36.4 lbs |
