Digital Display Torque Wrench,9x12,14x18mm,MTE-1 Series
-
Brand SAIVS Customized OEM,ODM L/W/H(mm) 230-557/45-47/40-45 Minimum Order 1Piece Model Number MTE-1 Place of Origin China Specification 9x12,14x18 Torque range(Nm) 2-500Nm Weight(kg) 0.48-1.78 - 150-500Nm,Pneumatic Torque Wrench,SFW5A 1800-6000Nm,Pneumatic Torque Wrench,SFW60A 240-800Nm,Pneumatic Torque Wrench,SFW8A 2400-8000Nm,Pneumatic Torque Wrench,SFW80A 3000-10000Nm,Pneumatic Torque Wrench,SFW100A 3600-12000Nm,Pneumatic Torque Wrench,SFW120A 405-1350 Nm,Pneumatic Torque Wrench,SFW14A 600-2000Nm,Pneumatic Torque Wrench,SFW20A 80-300Nm,Pneumatic Torque Wrench,SFW3A Pneumatic Torque Wrench SFW-A Series
Description
Supports both clockwise and counterclockwise operations
Colorful LCD display screen
Equipped with LED sound and light alarm function
Automatically reduces brightness within a minute to extend usage time
Handle made of high-quality imported material, providing excellent grip feel
Chip overload protection with bottom layer protection function
Multiple unit options available: N.m, Lb.ft, Lb.in, kg.cm
Interchangeable head design with 9x12 and 14x18 concave square head Torque Wrench interface.
Image Gallery
Dimensions
| MTE-1 Type Digital display torque wrench | |||||||||
| Model Number | Torque range | Specification | Length/mm | Width/mm | Height/mm | Weight/kg | Accuracy | ||
| N.m | Lbf.ft | straight | burden | ||||||
| MTE02801 | 2-10 | 1.5-4.5 | 9x12 | 230 | 47 | 40 | 0.48 | ±2% | ±3% |
| MTE02802 | 3-30 | 2.3-23 | 9x12 | 230 | 47 | 40 | 0.48 | ±2% | ±3% |
| MTE02803 | 6-60 | 4.5-45 | 9x12 | 376 | 45 | 45 | 1.02 | ±1% | ±2% |
| MTE02804 | 10-100 | 7.5-75 | 9x12，14x18 | 376 | 45 | 45 | 1.02 | ±1% | ±2% |
| MTE02805 | 20-200 | 15-150 | 14x18 | 557 | 45 | 45 | 1.48 | ±1% | ±2% |
| MTE02806 | 30-300 | 23-230 | 14x18 | 557 | 45 | 45 | 1.48 | ±1% | ±2% |
| MTE02807 | 50-500 | 38-380 | 14x18 | 557 | 45 | 45 | 1.78 | ±1% | ±2% |
Details
Application
Tightening lug nuts on a car wheel
Working on lawnmower blades
Aircraft maintenance
Attaching vehicle suspension components
Heavy equipment maintenance
Medical device assembly
Robotics and automation
Video
Literature
- 1.Working principle of manual torque wrenches
- 2.Repair Methods For Digital Torque Wrench
- 3.How Often Should I Calibrate My Torque Wrench
- 4.Types of Manual Torque Wrenches
- 5.Precautions for using preset torque wrenches
- 6.Basic knowledge of dial torque wrench
FAQs
How accurate is a digital torque adapter?
The accuracy of a digital torque adapter can vary depending
on the quality and calibration of the specific model.
Generally, high-quality digital torque adapters have accuracy levels within
+/- 2-3% of the indicated value. However, it's important to regularly calibrate
and verify the accuracy of the adapter to ensure consistent and reliable torque measurements.
Regular maintenance, adherence to calibration guidelines,
and using traceable standards can help maintain accuracy.
Are digital torque wrenches any good?
Yes, digital torque wrenches are highly regarded for their accuracy and convenience.
They offer precise torque measurement and often come with additional features like
digital displays, visual and audible alerts, and memory storage of torque values.
Digital torque wrenches provide real-time torque readings,
making them ideal for applications where precise torque control is necessary,
such as in automotive, aerospace, and industrial settings.
